GRANDO

B-Series

BRAND

GRANDO

MODEL

B-SERIES

RIP SOFTWARE

Photoprint10.5 or maintop V5.30

PRINT HEAD

KONICA-KM512i

Printing Speed

KM512i-30PL

4 HEADS

2PASS 110sqm/H/
3PASS 75sqm/H

KM512i-30PL

8 HEADS

2PASS 220sqm/H/
3PASS 140sqm/H

INK TYPE

COLOR

4 Colors(C,M,Y,K)/6 Colors(C,M,Y,K,LC,LM)

TYPE

Solvent Ink

CAPACITY

5L per Main Tank of Each Color

INK SUPPLY

Low Ink Dectector,Auto or Manual Ink Supply System

SPECIFICATION

width

3300mm(10.8ft)

Auto media feeding system

Equipped(Max, Midea wight 120KG)

media type

Vinyl, Polyester, Flex, Back-lit film, Window film, etc

auto cleaning system

positive pressure cleaning anti-clogged flash function capping system.

pre-heating & drying System

Equipped(Drying system optinal)

Clamp

Equipped

Print interface

USB 2.0

printhed height

2 to 4mm above media adjustable

Input power

AC 200V, 50Hz

Operating environmet

Tempeture: 20-28C HUMIDITY 40%-60%

Machine dinmesion / N.W

L500XW1275XH1580MM:net weight:880KG

Package dinmesion/G.W

L5150xW1120*H1860;Gross weight: 1000KG;Two units in one 20 feen container
