Features

1. Lead material by rubber pole, avoiding the material's stickup.
2. Equipped front/rear drying heater and matching cooling system, making printing picture dry faster.
3. Equipped feeding system of single pole, avoiding the materials excursion and rexaltion.At the same time, also equipped feeding system of double poles, providing flexbile choices, Equips with innovate electrical pinch roller system which is controlled by button. Thoughtful consideration for operators.
4. Equipped innovate electric pinch roller system controlled by 4buttons around the machine, Thoughtful consideration for operator a balance is equipped at the take-up to make the material neater
5. Set up a place for monitor, making good look and convenient operation.
6. USB interface is equipped at the operating station for more convenient opreation. Equipped efficient and convenient capping cover benefiting for the daily maintenance of print head.
7. Equipped a balance bar for material taking up, making material taking up more regular.
8. Equipped printing platform lamp, making printing picture obvious.
9. Setup USB interface and start button of computer, more convenient to operate.
10. With luxury machine body, benefiting to improve enterprise image. 800*400.

BRAND

PHAETON

MODEL

K-SERIES

RIP SOFTWARE

MAINTOP, ULTRA PRINT, PHOTOPRINT, WASATCH, TOPAZ

PRINT HEAD

SEIKO SPT510-50PL

SPECIFICATION


MEDIA TYPE

Vinyl, window Film, Polyester, Flex,
Back-lit Film, Etc.

Auto media feeding system

Equipped (Max, Media weight 80KG)

auto cleaning system

Individual postive pressure cleaning
Anti-clogged flash function & capping system

pre-heating & drying system

Equipped

Clamp

Equipped

print interface

USB 3.0

printhead height

2 to 6 mm from media

input power

AC 220V,50Hz/60Hz

machine dinmesion/ N.W

L4, 786xW1,1000xH1,350mm/685KG

package dinmesion/G.W

L4,980xW1,400xH1,640mm/968KG
